Researchers develop catalyst to improve butadiene production

\

Researchers develop catalyst to improve butadiene production

Researchers have developed a new catalyst that improves the efficiency of converting butane, a component of natural gas, into butadiene — a widely-used building block in synthetic rubber and a variety of plastics.

Creating butadiene from butane is tricky. Existing techniques for converting butane into butadiene either create a bunch of byproducts that nobody wants, or convert only a small fraction of the butane into butadiene each time the butane passes through the chemical reactor. As a result, butane has to go through the same process repeatedly.

“This is an expensive process in terms of both energy and money,” says Fanxing Li, corresponding author of the work and Alcoa Professor of Chemical and Biomolecular Engineering at North Carolina State University. “Because after every pass through the chemical reactor, you have to separate the butadiene and byproducts from the butane — which takes a lot of energy — and run the butane through the reactor again.”

Because of this, there are very few plants devoted to producing butadiene. Instead, much of the butadiene used in manufacturing comes from plants where butadiene is collected as a byproduct of other reactions.

“That’s a problem, because the demand for butadiene far outstrips the available supply,” Li says. “We wanted to come up with a more efficient way of converting butane into butadiene, making butadiene production facilities more commercially viable — and this work is an important step in that direction.”

Specifically, the researchers have engineered a catalyst that converts more butane into butadiene with each pass through the reactor, compared to previous catalysts. The work was done using an oxidative dehydrogenation reaction.

“We were able to convert up to 42.5% of the butane into butadiene in a single pass,” Li says. “The previous best performance we could find was around 30%. This is a big first step, but we view it as a proof of concept — we think we can still do a lot more to improve the selectivity of this process.”

The catalyst itself is a lithium bromide shell surrounding a core of lanthanum strontium ferrite. The reaction requires a modular reactor, and conversion takes place at between 450 and 500 degrees C.

“We’re open to partnerships to further explore the potential of this work,” Li says.

The paper, “Alkali metal halide coated perovskite redox catalysts for anaerobic oxidative dehydrogenation of n-butane,” was published in the journal Science Advances.
