UK-headquartered polymers firm Synthomer Plc, has linked up with the University of Loughborough in a project aimed at developing the next generation of concrete manufacturing technology. The project is led by construction experts at the UK university and supported by a grant of £1.2 million from the EPSRC’s Industrial Strategy Challenge Fund (ISCF). The project team also includes Autodesk; Concrenetics; Cundall; Foster + Partners; University of Sheffield; and Urbastyle.
3D Concrete Printing (3DCP) is a digitally-driven, off-site manufacturing technology that is establishing itself worldwide as a viable manufacturing process. However, its use beyond purely aesthetic objects is currently limited by the manufacturing accuracy achievable. The work undertaken by this group will develop the next generation, Hybrid Concrete Printing (HCP), technology that uses 3DCP to create a near-net-shape (an object slightly larger than the desired object) and then uses a subtractive process (cutting, milling and drilling) to remove a small amount of material to create the net-shape – the desired object to sub-millimetre precision. HCP technology offers an alternative to traditional cast concrete, freed from the need to construct moulds and traditional constraints on form and finish.
The project team has mapped out the global impact of the project thorough a supply chain initiative they refer to as MADE: Materials, Automation, Design and End user.
Materials: New polymer products developed and marketed by Synthomer for use as components of the concrete admixture used to modify the performance and properties of the printed concrete. Such components could, for example, control the rate at which the concrete flows and the rate it dries at, building on Synthomer’s portfolio of construction materials.
Automation: The digital work flow used during printing and subsequent subtractive HCP operations will inform future developments of the Autodesk Powermill software capability. This builds on Autodesk’s success with the hybrid welding process used to create the world’s first 3D printed ship’s propeller WAAMpeller. The HCP project will also open up new opportunities for concrete design, freed from traditional constraints on form and function.
Design: The design methods will be embedded in software developed within Cundall and Foster + Partners, to enable them to design for manufacture using 3DCP and HCP. This capability places both organisations ready to deliver HCP as a solution for clients.
End user: Concrete street furniture designer and manufacturer Urba-Style, together with HCP tool and concrete manufacturer Concrenetics, provide an established route to market for the technology.
The project is led by Professor Richard Buswell of the Loughborough School of Architecture, Building and Civil Engineering. Richard has over 30 years’ experience in building systems engineering in both industry and academia, and has been working in the field of additive manufacturing in the construction sector for more than 15 years.
An industry focused case study report will be written, making the case for the commercial viability of HCP. This will be disseminated through dedicated industry workshops and dissemination partners, e.g. the BRE, to promote the technology, attract investment, engage potential customers and other organisations interested in becoming part of the technology supply chain.
Towards the end of the project, the companies will take a stand at the 2021 UK Concrete Show (+180 exhibitors) to showcase the project outcomes to the wider UK and international concrete industrialists and public through the stand and technical lectures.
